SSAD-SB-700.1
people are viewing this right now
Description
1 Ohm Stable Class D
High Efficiency PWM Supply
Variable Low Pass Crossover
Thermal Protect
Short Circuit Protect
Overload Protect
Specifications
| MPLIFIER | SSAD-SB-700 |
| bass level remote control (16.4) | yes |
| low pass filter | 80hz-10khz |
| High pass filter (variable) | 15hz-80hz |
| subsonic Filter | 0-50hz |
| Frequency response (-1 db | 15hz-10khz |
| signal to noise ratio ('a' wtd) | >100db |
| input sensitivity | 30mv-6v |
| input impededance | 22k ohm |
| operation voltage (negative ground) | dc 12v |
| speaker impededance @stereo driven | 10hm |
| Fuse Rating | n/a |
| Dimensions | 115x225x67 |
| Stability / impedance note | RMS @ 1 Ohms (W) | RMS @ 2 Ohms (W) |
| 1 Ohm stable Class D | 700 | 350 |
